The effectiveness of caries prevention in patients with enamel defects of noncarious origin at the stages of orthodontic treatment

Full Text

BACKGROUND

Despite advances in orthodontic treatment over the past 20 years, the development of dental caries such as white spots around braces remains a problem. The incidence of white spots, based on post-treatment evaluations, ranges from 0% to 97%. Five risk factors for the development of dental caries in the form of white spots during treatment have been identified: treatment duration >36 months, teeth without fluorosis, poor oral hygiene, poor oral hygiene after the installation of fixed appliances, and presence of enamel defects [1–4]. Dental caries are prevalent in the general population, with reports indicating that 20%–80% of people worldwide have enamel defects. Patients with such defects often require orthodontic treatment. The wide range of enamel defects reported is mainly due to the inclusion criteria for what constitutes an enamel defect, such as enamel hypoplasia or its absence, discoloration indicating hypomineralization, fluorosis, and caries. Environmental exposure and genetic changes can impair enamel development. Pathological conditions such as fever, infection, trauma, saturation changes, antibiotic therapy, and other factors can adversely affect amelogenesis. The enamel phenotype resulting from different types of damage during amelogenesis varies depending on the type of stress, duration, and intensity of exposure. Short-term environmental stressors such as fever often cause localized enamel defects, whereas chronic stressors such as increased fluoride exposure are more likely to be associated with generalized defects [5–10]. When treating patients with enamel defects who require orthodontic treatment with fixed appliances, planning for caries prevention programs considering the enamel structure is important.

Numerous studies have evaluated the effectiveness of methods to prevent white enamel spots during orthodontic treatment. The development of fluoride materials for braces is currently underway. Oral hygiene must be maintained using high-fluoride toothpaste and professional preventive products. The combined use of fluoride, hydroxyapatite, and calcium compounds has been a recent topic of debate [11–22]. Studies have confirmed the effectiveness of deep enamel fluoridation [23–29].

The aim of this study was to determine the effectiveness of prophylaxis around brackets and in noncarious spots during orthodontic treatment in patients with enamel defects.

MATERIALS AND METHODS

The study enrolled 54 patients aged 14–18 years, who were divided into three groups. Each group was offered a choice among the three caries prevention algorithms to determine which was the most acceptable.

Group 1 consisted of 20 patients with a mean age of 16.5 years and a hygiene index was 64.32% ± 8.92%. This group presented with noncarious spots. After the installation of the bracket system, all patients received monthly professional oral hygiene. Subsequently, “Fluorine-Lux” (TechnoDent, Russia) was applied around each bracket and on all enamel defects for deep fluoridation. The enamel was first impregnated with a liquid containing magnesium hexafluorosilicate and slightly dried to increase the concentration. Then, it was treated with calcium hydroxide suspension. This interaction resulted in the formation of insoluble crystalline salts of magnesium and calcium fluorides in a silicic acid gel, which trapped the crystals in the enamel defects around the bracket or adhesive.

Patients were advised to use ROCS ProBrackets & Ortho toothpaste twice daily for home oral hygiene. Group 2 included 18 patients with a mean age of 16.8 years and a hygiene index of 62.57% ± 7.16%. This group presented with noncarious spots. After the installation of the bracket system, all patients received monthly professional oral hygiene. Subsequently, the “Fluorine-Lux” varnish (TechnoDent, Russia) was applied around each bracket (bracket glue) and on all enamel defects. The varnish contains calcium fluoride, sodium fluoride, aminofluoride, and a film-forming agent in a volatile solvent. Patients were advised to use ROCS ProBrackets & Ortho toothpaste twice daily for home oral hygiene.

Group 3 included 16 patients with a mean age of 16.4 years and a hygiene index of 66.34% ± 6.53%. This group had noncarious spots. After the installation of the bracket system, professional oral hygiene was performed every 6 months, followed by fluoride varnish application. The patients used toothpaste containing monofluorophosphate twice daily for home oral hygiene.

Oral cavity sanitation was performed in all patients before and during the installation of the bracket system and the stages of treatment. The average treatment period was no longer than 30 months. Caries intensity was assessed after oral cavity sanitation. The “D” component included caries in staining stage K02.0. Noncarious enamel defects, classified in ICD10 under codes K00.4 and K00.5, were also noted. Patients with confirmed diagnoses of dental fluorosis (K00.30) were excluded according to the criteria. The differential diagnosis between carious and noncarious stains was made using vital staining and fluorescence diagnostics after plaque removal. If staining was not detected and porphyrin fluorescence was absent, enamel defects (K00.4 and K00.5) were noted. If staining was detected and porphyrin fluorescence was present, caries (K02.0) was noted. Methylene blue solution was used for staining, and VistaCam was used to determine fluorescence (Figs. 1 and 2).



Fig. 1. Spot without signs of demineralization; enamel hypomineralization of noncarious origin (postnatal hypoplasia, K00.4)

Рис. 1. Пятно без признаков деминерализации — гипоминерализация эмали некариозного происхождения (постнатальная гипоплазия К00.4)



Fig. 2. Stain with signs of demineralization in the subsurface layer (caries, K02.0)

Рис. 2. Пятно с признаками деминерализации в подповерхностном слое (кариес К02.0)



The oral hygiene index was determined by staining teeth with an indicator and counting the number of stained surfaces of all teeth using the Hygiene Efficiency Index (O’Leary, 1967). The proportion of stained surfaces to the total number of tooth surfaces was then calculated as a percentage. Enamel resistance was measured using the test of enamel resistance (TER-test) (Okushko V.R., Kosareva L.I., 1984).

Test procedure: A drop of 1% hydrochloric acid solution was applied to the cleaned and dried vestibular surface of the premolar enamel using a microcapillary at the center for 5 s. After the removal of the acid, a 1% aqueous solution of methylene blue was applied to the etched areas using a microcapillary. The staining intensity was evaluated using a 10-field typographic shade scale for blue with a colorimetric gradation of saturation ranging from 10% to 100%. To interpret the results, the staining intensity indicates the level of tooth enamel resistance to acidic factors. If the staining intensity is <30%, the tooth enamel is resistant to these factors. If the staining intensity is between 30% and 60%, the tooth enamel has a moderate degree of resistance to acidic factors. If the staining intensity is >60%, the tooth enamel is unstable under the influence of acids. The indices were registered twice, i.e., before the installation of the bracket system and after its removal.

Statistical data were processed using the Statistica 12.0 program.

RESULTS

The hygiene index was not significantly different before the installation of the bracket system and after its removal in the three groups. However, the hygiene index values before and after treatment were significantly different, indicating a significant improvement in the oral hygiene of all patients (Table 1). The populations being compared exhibited a normal distribution. Differences between the groups were not significant (p > 0.01). However, significant differences in the hygiene index were noted before and after the removal of the braces (p < 0.05).



Table 1. Hygiene index of the patients in the study groups

Таблица 1. Индекс гигиены у пациентов групп исследования

Determination period	O’Leary hygiene index, %
	Group 1	Group 2	Group 3
Before bracket placement	64.32 ± 8.92	62.57 ± 7.16	66.34 ± 6.53
After treatment	34.45 ± 6.31	38.73 ± 6.97	35.84 ± 7.28



In the assessment of tooth enamel resistance in group 1, the hygiene index values were 42.32% ± 4.35% and 43.98% ± 2.11% before and after treatment. The difference was not significant (p > 0.01) (Table 2).



Table 2. Resistance of tooth enamel by the test of enamel resistance in the study groups

Таблица 2. Резистентность эмали зубов по ТЭР-тесту у пациентов групп исследования

Determination period	ERT, %
	Group 1	Group 2	Group 3
Before bracket placement	42.32 ± 4.35	38.93 ± 4.17	44.02 ± 4.38
After treatment	43.98 ± 2.11	49.48 ± 5.09	67.38 ± 3.21



In group 2, the enamel resistance rate before treatment was 38.93% ± 4.17%, which significantly increased to 49.48% ± 5.09% after brace removal. In group 3, the TER-test value was 44.02% ± 4.38% before treatment, which significantly increased to 67.38% ± 3.21% after the removal of the bracket system (p < 0.05). Before the installation of the bracket system, no significant differences in the TER-test values were found among patients in all groups. After treatment, enamel resistance in group 3 decreased significantly compared with the initial values, whereas groups 1 and 2 did not experience significant changes in TER-test values.

In this study, no patients had cavitated carious defects because their oral cavities were sanitized before brace system placement. The “D” component included caries in the staining stage (K02.0). Enamel defects were classified as K00.4 and K00.5. Importantly, the intensities of caries and noncarious lesions before treatment were comparable among the three groups and did not show significant differences.

Before placing the bracket system in group 1, the caries intensity was 11.42 ± 1.08. Carious stains were recorded at 2.42 ± 0.05 and noncarious stains at 5.52 ± 0.03.

After the removal of the bracket system, the intensity of caries in this group significantly increased to 13.75 ± 1.12 (p > 0.01), and the “D” component increased to 2.91 ± 0.38 (p > 0.01). The number of teeth with enamel defects remained the same, which may indicate a stable situation regarding dental caries in the area of enamel defects of noncarious origin (Table 3).



Table 3. Intensity of caries in dynamics in two study groups

Таблица 3. Интенсивность кариеса в динамике у двух групп исследования

Study groups	D (К02.0)	F	M	DMF	ED (К00.4, К00.5)
Group 1
Before bracket placement	2.42 ± 0.15	9.34 ± 0.09	–	11.42 ± 1.08	5.52 ± 0.03
After brace removal	2.91 ± 0.38	10.87 ± 0.11	–	13.75 ± 1.12	5.52 ± 0.03
Group 2
Before bracket placement	2.34 ± 0.02	8.96 ± 0.18	–	10.98 ± 0.25	6.19 ± 0.09
After brace removal	3.42 ± 0.19	9.27 ± 0.12		12.23 ± 1.34	4.19 ± 0.06
Group 3
Before bracket placement	6.12 ± 0.10	8.09 ± 0.11	–	11.25 ± 0.09	6.09 ± 0.02
After brace removal	6.83 ± 0.11	12.12 ± 0.08	–	18.21 ± 0.16	3.98 ± 0.04
Note: D, decayed teeth; M, missing teeth; F, filled teeth; ED, enamel defects.



In group 2, the intensity of dental caries before orthodontic treatment was 10.98 ± 0.25, and the number of teeth with noncarious defects was 6.19 ± 0.09. After the removal of orthodontic appliances, the intensity of the carious process in group 2 significantly increased to 12.23 ± 1.34 (p < 0.05), and the number of teeth with noncarious defects significantly decreased to 4.19 ± 0.06 (p < 0.05). The “D” component also increased significantly to 3.42 ± 0.19 (p < 0.05).

In group 3, the intensity of dental caries before orthodontic treatment was 11.25 ± 0.09, the “D” component was 6.12 ± 0.10, and the number of teeth with noncarious defects was 6.09 ± 0.02. After the removal of orthodontic appliances, the intensity of the carious defects increased significantly to 18.21 ± 0.16 (p < 0.05), the “D” component increased to 6.83 ± 0.11 (p < 0.05), and the number of teeth with noncarious defects decreased to 3.98 ± 0.04 (p < 0.05).

New carious spots were detected along with cavitated defects that required treatment and filling in teeth with noncarious enamel lesions.

CLINICAL CASE. PATIENT WITH ENAMEL HYPOPLASIA BEFORE AND AFTER TREATMENT

Patient M, a 15-year-old girl, was diagnosed with mesial occlusion, retention of teeth 4.3 and 3.3, postnatal systemic enamel hypomineralization, and celiac disease (gluten enteropathy), as shown in Figure 3.



Fig. 3. Patient M.’s teeth before (a) and after (b) treatment

Рис. 3. Фотографии зубов пациента М. до (а) и после (b) лечения



Before bracket system placement, the decayed/missing/filled teeth (DMF) index was 4, the TER value was 44%, the hygiene index was 58%, and noncarious spots were present in 24%. The treatment period was 25 months. After removing the bracket system, the DMF index was 5. The TER-test value and the hygiene index were 46% and 43%, respectively. In addition, noncarious spots were observed in 24% of the cases.

CONCLUSIONS

To prevent white spots in patients with noncarious lesions during orthodontic treatment, monthly professional oral hygiene with arch removal is recommended. The most effective approach is to combine home oral hygiene with a calcium-containing paste and monthly application of Fluorine-Lux (TechnoDent, Russia) for deep fluoridation around the brackets and in the area of the noncarious spots.

ADDITIONAL INFORMATION

Authors’ contribution. All the authors made a significant contribution to the preparation of the article, read and approved the final version before publication. Personal contribution of each author: E.A. Satygo — collecting material, writing and editing the text of the manuscript; S.A. Popov — collecting material, analyzing the data obtained, writing the text of the manuscript.

Funding source. The authors claim that there is no external funding when writing the article.

Competing interests. The authors declare the absence of obvious and potential conflicts of interest related to the publication of this article.

Ethics approval. The material of the article demonstrates the results of clinical observation, does not contain research materials.

Informed consent to publication. All participants voluntarily signed an informed consent form prior to the publication of the article.
